ABB DSQC233 YB560103-BS/1 – Advanced Axis Control Module

Operating Voltage:DC 24V

Input Current:10mA max per channel

Output Current:20mA per channel

Max. Number of Channels:16

Communication Protocol:EtherCAT

Temperature Range:-20°C to +70°C

Mechanical Dimensions:84mm x 51mm x 24mm

Weight:45g

    Integrating advanced microcontroller technology, the ABB DSQC233 YB560103-BS/1 Axis Board ensures precise and reliable control in complex industrial environments. Its robust design withstands harsh conditions, making it ideal for use in manufacturing and robotic systems.

    Featuring an open communication protocol, this board seamlessly integrates with ABB‘s Robotware and ABB Ability™ platforms, allowing for seamless data exchange and enhanced automation capabilities.

    With its high-speed processing at 64KHz, the DSQC233 can handle a large volume of input and output tasks simultaneously, significantly improving production efficiency.

    Capable of handling up to 24 input signals and 16 output channels, it provides ample flexibility for various automation requirements, ensuring compatibility across different machinery and systems.

    Built with durability in mind, the compact yet sturdy design of the DSQC233 YB560103-BS/1 ensures longevity and minimal maintenance, reducing downtime and increasing operational efficiency.
