Model Number:1746-IM16
Module Type:Digital AC Input Module
Number of Channels:16
Input Voltage Range:10 – 30 VAC, 10 – 30 VDC (Sink)
Off-State Input Voltage:3 VAC/VDC
Nominal Current:8 MA At 24 VAC/VDC
Off-State Current:1 MA AC/DC
Isolation Levels:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Environmental Conditions:Temperature Rating: 0 – 60 DEG C, Relative Humidity: 5 – 95% Non-Condensing
Shock Resistance:30 G
Engineered for industrial strength and reliability, the Allen Bradley AB 1746-IM16 SLC 500 Digital AC Input Module is an essential component for any high-demand automation system. With its 16-channel design, it ensures efficient processing and transmission of digital AC signals, crucial for accurate data acquisition.
This module boasts a wide range of input types, accommodating both AC and DC signals, which is particularly advantageous in diverse industrial applications. Its off-state voltage drop minimizes interference, ensuring clean signal integrity even under varying conditions.
Featuring advanced isolation technology, the Allen Bradley AB 1746-IM16 module safeguards against electromagnetic interference, maintaining high performance in challenging environments. The open-type enclosure facilitates easy installation and maintenance, while the chassis mounting option ensures secure integration within existing systems.
Operating within a temperature range from 0 to 60 degrees Celsius, this module is designed for durability in extreme conditions, making it suitable for a wide array of industrial settings. Additionally, its ability to withstand shock up to 30G ensures robustness during transportation and operation.
The Allen Bradley AB 1746-IM16 Digital AC Input Module is engineered to seamlessly integrate into existing Allen-Bradley automation networks, offering enhanced connectivity through its Ethernet/IP, DH+, DH-485, and RS-232 communication options. This compatibility streamlines system integration and boosts overall operational efficiency.
