Model Type:SLC500
Model Number:1746-OX8
Manufacturer:Allen-Bradley
Isolation:500 VDC communication circuits
Backplane Isolation:1500 VAC
Processor:SLC 500
Enclosure Type:Open
Mounting Type:Chassis
Temperature Rating:0 – 60°C
Environmental Conditions:5 – 95% RH
Input Voltage:5 – 50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 MA
Load:1 MA
Current Rating:Backplane: 190 MA, Continuous per output: 0.25 A at 60°C, Continuous per module: 8 A at 60°C
Impedance:Greater than 1 MOHM
The Allen-Bradley 1746-OX8 Output Module is engineered for seamless integration into complex industrial control systems, offering exceptional performance and reliability.
Each isolated relay output ensures safety and precision in signal transmission, making it ideal for applications requiring isolation from noise and voltage fluctuations.
With its robust design and advanced features, this module supports up to 64 K words of configurable data and program memory, enabling sophisticated control logic and extensive system scalability.
Capable of managing up to 4096 input and output signals, it facilitates efficient monitoring and control of remote I/O across various networks, enhancing operational efficiency.
Built-in support for EtherNet/IP, DH+, DH-485, and RS-232 communication protocols ensures seamless connectivity and interoperability with a wide array of industrial devices, maximizing flexibility and compatibility within the manufacturing environment.
