Allen-Bradley 1790D-T16BV0 Compact Block I/O Module

Manufacturer:Allen-Bradley

Model:1790D-T16BV0

Type:Compact Block I/O Modules

Input Voltage Range:10 – 30 VDC

Input Current:0.5 A

Output Channels:16 (2 Groups Of 8)

Voltage Rating:24 VDC

Current Rating:Module: 4 A, Surge: 1 A

Isolation:500 VAC

Enclosure:IP20, Open Type

Communication Protocol:DeviceNet

Mounting:DIN Rail, Panel

Dimensions:Length: 1.9 IN, Width: 1.5 IN, Height: 4.4 IN

Temperature Rating:0 – 60 DEG C

Environmental Conditions:Non-Operating Temperature: -40 DEG C

Weight:N/A

    The Allen-Bradley 1790D-T16BV0 Compact Block is a high-performance modular input/output (I/O) module, designed to offer exceptional reliability and efficiency in industrial control applications. Its compact design allows for easy integration into various control systems without compromising on functionality or performance.

    Featuring a robust input voltage range of 10 to 30 VDC and a current rating of up to 0.5 A per channel, this module ensures compatibility with a wide range of sensors and actuators. The built-in surge protection safeguards against transient overvoltages, enhancing system uptime and durability.

    With a voltage rating of 24 VDC and a current rating of up to 4 A for the module and 1 A for surges, the 1790D-T16BV0 provides ample power for demanding control tasks. Its IP20 open type enclosure ensures protection against dust and non-corrosive liquids, ideal for industrial environments.

    Equipped with DeviceNet communication capability, this module seamlessly integrates with Allen-Bradley’s programmable logic controllers (PLCs) and other compatible devices, enabling sophisticated automation and control solutions. The choice of mounting options—DIN rail or panel—facilitates flexible installation scenarios.

    Engineered for a temperature range of 0 to 60 DEG C, the 1790D-T16BV0 is designed to withstand harsh industrial conditions, ensuring reliable operation throughout its service life. This module is an excellent choice for applications requiring high-speed data processing, precise control, and efficient energy management.
