Allen Bradley AB 1746-OB32E SLC 500 DC Output Module – High-Performance, Efficient Control Solutions

Model Type:SLC 500

Model Number:1746-OB32E

Manufacturer:Allen Bradley

Digital DC Output:true

Number of Channels:32

Output Voltage Range:5 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capability:1 MA

Current Rating:{“Backplane”:”190 MA”,”Continuous Current Per Output”:”0.25 A At 60 DEG C”,”Continuous Current Per Module”:”8 A At 60 DEG C”}

Isolation:{“Communication Circuits”:”500 VDC”,”Backplane”:”1500 VAC”}

Processor:SLC 500

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95%

Shock Resistance:N/A

    Experience unparalleled precision and reliability with the Allen Bradley AB 1746-OB32E SLC 500 Digital DC Output Module. This robust module is engineered to handle demanding industrial automation tasks, featuring a high channel count of 32 for versatile application possibilities.

    Each output channel is equipped to deliver voltage ranges from 5 to 50 VDC, ensuring compatibility with a wide array of devices and systems. The on-state voltage drop of 1.2 V ensures efficient power management, while the low off-state output leakage of 1 MA minimizes power consumption when inactive.

    Designed for seamless integration into existing systems, this module boasts an open type enclosure that can be easily mounted onto a chassis. Its temperature rating of 0 to 60 DEG C allows for operation in various industrial environments, backed by a non-condensing relative humidity range of 5 to 95%, ensuring consistent performance under diverse conditions.

    With a current rating of 190 MA for the backplane and 8 A per module, the Allen Bradley AB 1746-OB32E is built for high throughput operations, making it ideal for complex automation scenarios. The built-in isolation features, including 500 VDC for communication circuits and 1500 VAC for the backplane, safeguard against electrical interference, enhancing system stability and longevity.

    Equipped with the advanced SLC 500 processor, this module offers unmatched computational power and flexibility, enabling sophisticated control strategies tailored to specific automation needs. Whether you’re optimizing production lines, managing complex machinery, or integrating with cutting-edge IoT technologies, the Allen Bradley AB 1746-OB32E is your trusted partner in driving industrial innovation.
