Control Power nominal:20 VA
Control Power maximum:65 VA
Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz
Dimensions:Approximately 12 in H x 5 in W x 8 in L
Ground Current Input Frequency:20 to 100 Hz
Insulation Class:Class I
Phase Current Input Conversion:True RMS, 1.04 ms/sample
Weight:Approximately 4.5 kg
Optional Features:Metering Package
Communication Interfaces:Non-isolated RS232 port, RS485 port
Event Record Triggers:Power fail, Alarms, Self-test, Inhibit, Trip, Waveform Capture
Operating Range:-40°C (-40°F) to +60°C (140°F)
Storage Range:-40°C (-40°F) to +80°C (176°F)
The GE 369-HI-0-M-0-0 Motor Management Relay is designed to ensure the safety and efficiency of medium to large motors through advanced protection and monitoring technologies.
It offers a wide range of protection features including undervoltage auto-restart, reverse power protection, and detection of mechanical jams.
With built-in metering capabilities like event reports, waveform captures, and startup data logging, this relay provides critical insights into motor performance and helps predict potential failures.
This robust relay supports voltages ranging from 50-300 VDC to 40-265 VAC, making it suitable for various industrial settings.
Additionally, the relay’s user-friendly design allows for easy installation and maintenance, reducing downtime and enhancing overall operational efficiency.
