Brand:GE
Model:DS3800XAIB1E1E
Category:Circuit Board
Subcategory:Industrial Control
Board Type:DS3800 Series
Dimensions:330mm x 250mm x 50mm
Weight:1.5kg
Connectors:10 Connector Ports
Test Points:10 Additional Test Points
Components:Various PCB Components including Resistors, Capacitors, Diodes
Material:Black Plastic and Silver-Gold Metal
Power Supply:AC/DC Compatibility
Operating Temperature Range:-40°C to +70°C
Compatibility:Mark IV DS3800 Systems
The GE DS3800XAIB1E1E Circuit Board is meticulously engineered to offer unparalleled performance in turbine control applications. Its robust design includes a series of large components arranged on one half of the board, providing critical functions for system optimization. The smaller components, predominantly resistors, are strategically placed on the other half, ensuring efficient signal processing and system stability.
Crafted from high-quality materials, this circuit board is characterized by its durability and reliability under demanding industrial conditions. The use of both black plastic and silver-gold metal materials ensures a balance between functionality and longevity, making it a preferred choice for professionals seeking high-performance solutions.
With its comprehensive set of connector ports and test points, the DS3800XAIB1E1E offers versatile connectivity options, facilitating easy integration with a wide range of hardware and software systems. This feature not only enhances the adaptability of the board but also simplifies the setup process for users.
The presence of over thirty-five red LEDs on the board serves multiple purposes, from status monitoring to error detection, ensuring that system operators have immediate visibility into the operational state of their turbine control systems. Additionally, the inclusion of a small switch provides users with direct control over certain system functionalities, offering enhanced convenience and customization.
AX Control’s dedicated team stands behind the GE DS3800XAIB1E1E Circuit Board, offering expert support and guidance throughout the purchasing and integration process. Our comprehensive service package includes detailed installation guides, troubleshooting assistance, and access to a wealth of technical resources, ensuring a seamless experience for our valued customers.
