Manufacturer:GE Industrial Systems
Series:EX2100 Excitation Control
Part Number:IS200DSPXH1DBC
Functional Description:Digital Signal Processor Control Board
Functional Acronym:DSPX
PCB Coating:Conformal Coating
Functional Revision:1D
Artwork Revision:C
Instruction Manual:GEI-100488
Clock Speed:60 MHz
Interfaces:Two (Master or Slave) 5 Mb/s ISBus interfaces
The IS200DSPXH1DBC model from General Electric is meticulously crafted for the demanding needs of industrial automation. It features a high-frequency 60 MHz digital signal processor, ensuring swift and accurate data processing.
Integrated with an Application-Specific Integrated Circuit (ASIC), this control board offers exceptional performance and reliability, making it an indispensable component in various industrial applications.
This control board supports multiple inputs and outputs, providing versatile connectivity options for seamless integration with existing systems. With six backplane inputs and three I/O connectors, it caters to complex automation requirements.
Equipped with two LED indicators for fault and status monitoring, the IS200DSPXH1DBC ensures real-time visibility of operational conditions, facilitating prompt troubleshooting and maintenance.
The design includes a robust power supply input of 5V and a data bus function pin quantity of 32, enhancing its adaptability across different industrial settings.
