GE Multilin 745-W3-P5-G5-HI Transformer Management Relay, High Control Power

Weight:4.8 kg

Voltage Input Burden:Less than 0.025 VA at 120 V

Source VT:2 to 600 kV / 60 to 120 V

Logic Inputs:16

Manufacturer:General Electric Multilin

Fuse Current Rating:3.15 A

Operating Temperature:-40°C to +60°C

Input Voltage:60 to 120V

Display Resolution:40 Character LCD

IRIG-B Input Impedence:70 to 100 kΩ

    The GE SR745-W3-P5-G5-HI is a robust and versatile transformer management relay designed for use in demanding industrial settings.

     Its enhanced 40-character LCD display and expanded keypad facilitate easy manual entry of setpoints and real-time monitoring.

     With a compact design measuring 9 inches in height, 7 inches in width, and 7 ⅛ inches in depth, this relay fits seamlessly into standard 19-inch panels.

     The device can operate independently or in conjunction with other relays in the GE Multilin 745 series, ensuring comprehensive protection and management of transformers of all sizes.

     Key features include enhanced control power, user passcodes for security, and a high-resolution display that provides clear alerts and diagnostics.

     Additionally, the relay’s broad operating temperature range and humidity tolerance make it suitable for a variety of environmental conditions.
