Heidenhain CC422 ID359651-02 Encoder Module for Precision Measurement

Manufacturer:Heidenhain

Model Number:CC422

Part Number:ID359651-02

Measurement Range:360° continuous rotation

Resolution:13 bit

Output Signal:Sinusoidal signals (sin/cos)

Supply Voltage:10 to 30 V DC

Operating Temperature:-40°C to +100°C

Protection Class:IP64

Weight:Approximately 300g

Dimensions:Diameter: 42mm, Length: 90mm

    The Heidenhain CC422 ID359651-02 incremental encoder provides exceptional accuracy and reliability in industrial environments, making it ideal for a wide range of applications including manufacturing, robotics, and process automation.

    With its robust design featuring IP67 shaft sealing, this encoder ensures protection against dust and water ingress, enhancing its longevity and operational stability under harsh conditions.

    This model supports push-pull and RS422 output signals, allowing for flexible integration into existing systems and ensuring compatibility with a broad spectrum of controllers and drives.

    The 1024 PPR resolution ensures high precision in position feedback, enabling precise control over mechanical movements and processes, which is crucial for maintaining quality and efficiency in industrial operations.

    The compact and durable design of the Heidenhain CC422 ID359651-02 makes it easy to install and maintain, reducing downtime and operational costs for businesses relying on advanced automation solutions.
