Frequency Range:up to 50 MHz
Output Amplitude:2 Vpp to 10 Vpp
Waveform Types:Sine, Square, Triangle, Ramp, Noise, Arbitrary
Resolution:14-bit
Memory Depth:16 kSamples
Output Channels:2 Channels
The Tektronix 5A22N Arbitrary Function Generator is designed to meet the demanding requirements of precision testing and measurement. With its advanced waveform generation capabilities, it can produce a wide range of waveforms including sine, square, triangle, ramp, pulse, and arbitrary waveforms. This makes it an indispensable tool for engineers and technicians working in various fields such as electronics, telecommunications, and scientific research.
This model offers exceptional performance with a frequency range from 1 μHz to 50 MHz, ensuring it covers a broad spectrum of applications. Its 14-bit vertical resolution guarantees high accuracy and reliability, making it suitable for critical measurements where precision is paramount.
The Tektronix 5A22N includes multiple output options, including ±10 Vpp into 50 Ω, providing flexibility for different types of testing scenarios. The ability to adjust phase shift from 0° to 360° adds another layer of versatility, allowing users to fine-tune their signals as needed.
Triggering options include internal, external, software, and manual, giving users complete control over signal generation. The inclusion of USB, LAN, and GPIB interfaces ensures seamless integration with existing test setups and automated systems.
Designed with user convenience in mind, the Tektronix 5A22N features an intuitive interface and robust construction, ensuring reliable operation even in challenging environments. Its compact design allows for easy placement on workbenches or integration into larger test systems.
