Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Frequency Range:0.1 μHz to 20 MHz
Amplitude:±10 Vpp into 50 Ω
Resolution:14-bit vertical resolution
Output Impedance:50 Ω
Phase Shift:±90°
Sampling Rate:up to 100 MSa/s
Memory Depth:16 kPoints
Trigger Source:Internal, External, Manual, Bus
Display:5.6-inch color TFT LCD
Connectivity:USB, LAN, GPIB
The Tektronix 5b42 Arbitrary Waveform Generator is a versatile and reliable tool designed for engineers and researchers who need precise signal generation.
With its dual-channel output, it can generate a wide range of waveforms including arbitrary signals, making it ideal for complex test scenarios.
The 14-bit resolution ensures high-quality signal fidelity, and the memory depth of 16 kpts allows for detailed waveform creation and editing.
The generator supports multiple triggering options, including internal, external, manual, and burst, providing flexibility in various testing environments.
Its compact and robust design makes it easy to integrate into existing setups, while the intuitive user interface simplifies operation and setup processes.
Whether you’re developing new technologies or conducting rigorous testing, the Tektronix 5b42 delivers the precision and performance you need.
