Tektronix TDS544A Four-Channel Digitizing Oscilloscope, High-Speed Measurement Equipment

Channels:4

Bandwidth:1 GHz

Sample Rate:5 GS/s

Vertical Sensitivity:2 mV/div to 10 V/div

Input Coupling:DC, AC, Ground

Horizontal Time Base:50 ps/div to 10 s/div

Trigger Modes:Edge, Pulse Width, TV, Slope, Glitch, Window

Memory Depth:20 Mpoints

Display:9-inch SVGA Color Display

Interface:USB 2.0, Ethernet, GPIB

    The Tektronix TDS544A is designed for engineers who demand precise measurements and reliable performance in their daily tasks. With its four independent channels, you can analyze multiple signals simultaneously without the need for switching probes or inputs.

    Featuring a bandwidth of 400 MHz, this oscilloscope is capable of handling fast-changing signals with ease. Its sample rate of 2 GS/s ensures accurate capture of transient events.

    With a record length of 20 million points per channel, the TDS544A allows for deep analysis of long waveforms without compromising on detail. This is particularly useful for debugging complex systems.

    The oscilloscope comes equipped with a robust vertical sensitivity range from 2 mV/div to 10 V/div, making it suitable for a wide variety of applications, from low-voltage digital circuits to high-voltage power electronics.

    The user-friendly interface includes a large color display for clear visualization of waveforms. Additionally, the oscilloscope supports various data interfaces including GPIB, RS-232, USB Host, and USB Device, allowing seamless integration with other test equipment.
