Tektronix VX4240 Arbitrary Function Generator

Waveform Types:Sine, Square, Triangle, Pulse, Arbitrary

Frequency Range:up to 40 MHz

Amplitude Range:20 mVpp to 20 Vpp

Resolution:14-bit

Output Impedance:50 ohms

Sampling Rate:100 MSa/s

Memory Depth:8 Mpts

Phase Shift:0 to 360 degrees

    The Tektronix VX4240 Arbitrary Waveform Generator is designed to meet the stringent demands of modern industrial applications. This device offers unparalleled precision and flexibility in waveform generation, making it an indispensable tool for testing and validation processes. Key features include support for a wide range of waveform types such as sine, square, triangle, pulse, and arbitrary waveforms, which are essential for simulating real-world conditions. With a frequency range up to 40 MHz and an amplitude range from 20 mVpp to 20 Vpp, the VX4240 ensures accurate signal generation across multiple frequencies and amplitudes. Its high-resolution 14-bit DAC ensures excellent signal fidelity, while the 8 Mpts memory depth allows for detailed waveform creation and storage. Additionally, phase shift capabilities from 0 to 360 degrees enable precise control over signal characteristics, enhancing the accuracy and reliability of your tests. The VX4240’s robust design and ease of use make it an ideal choice for engineers and technicians looking to perform high-quality signal generation and validation tasks efficiently.
